Specification | VP80 |
|---|---|
Rated Pump Speed | 640 rpm / 520 rpm |
Flow Rate | 72 gpm @ 640 rpm / 58 gpm @ 520 rpm |
Viscosity Rating | Up to 5,000 SSU |
Horsepower | 2.5–3 hp |
Temperature Rating | Up to 300°F |
Differential Pressure | Up to 125 psi |
Working Pressure | Up to 175 psi |
- 2" NPT flanged ports for straightforward installation
- Flow rate up to 87 gpm at rated pump speed (per data sheet: “VP80: Flow rates to 87 gpm”)
- Pressure capability up to 125 psi with relief valve protection
- Pumps supplied with standard 110 psi setting and additional 125 psi relief spring for higher‑pressure operation
- Dual drive shafts for clockwise or counter‑clockwise rotation
- Buna or Viton seal options to match product compatibility
- Drive adaptors for SAE A hydraulic motor mounting
- Sliding vane design for quiet, efficient, low‑maintenance performance
1. Flow Requirements
The VP80 supports up to 87 gpm, making it ideal for small to mid‑range transfer operations. If you need more capacity, compare with:
- VP150: Up to 157 gpm
- VP270: Up to 270 gpm
2. Pressure Needs
The VP80 supports up to 125 psi differential pressure, with a relief valve included for safe operation.
3. Product Compatibility
Seal options (Buna, Viton) and high‑temperature capability (300°F) support oils, fuels, solvents, and petrochemicals.
4. Drive Configuration
Hydraulic motor mounting via SAE A adaptors makes the VP80 a strong fit for hydraulic‑powered systems.
